UT347A Leeb Hardness Tester is accurate and portable in size. It supports thermal printing and is especially suitable for field hardness testing of large equipment such as roller turboshafts, pressure vessel and turbine set. Widely used in petrochemical, electric power, automobile, shipbuilding, machinery manufacturing and other industries.
FEATURES:
- 6 kinds of hardness values (HL, HB, HRC, HRB, HV, HS) is a real-time measurement
- One hardness tester can be equipped with 7 different impact devices
- Automatic identification without calibration when replacing impact device
- Statistical, multi-unit, line chart, histogram 4 measurement modes
- Β Camera: 640Γ480 pixels (900 BMP format pictures could be stored)
- Automatic alarm when the upper and lower limits are exceeded
- Adjustable backlight brightness
- Mobile phone Bluetooth APP and PC software analysis data
- Support thermal printing
- Tri-color LED indication and LED flashlight.
INCLUDES:
1 xΒ UT347A, 1 x English manual and 12-month warranty
SPECIFICATIONS:
| Specifications | ||||||
| Functions | Impact device type | Standard Richter block hardness value | Resolution | Error value | Indication repeatability | instructions |
| Hardness measurement | D | 790Β±40HLD | 1HLD | Β±6HLD | 6HLD | Standard hardness blocks: 1. Standard D-type Richter hardness blocks A grade uniformity Β±1HLD; 2. Standard G Type Richter Hardness blocks, grade A uniformity Β±1HLG; |
| 530Β±40HLD | Β±10HLD | 10HLD | ||||
| DC | 790Β±40HLDC | 1HLDC | Β±6HLDC | 6HLDC | ||
| 530Β±40HLDC | Β±10HLDC | 10HLDC | ||||
| DL | 894Β±40HLDL | 1HLDL | Β±12HLDL | 12HLDL | ||
| 736Β±40HLDL | ||||||
| D+15 | 795Β±40HLD+15 | 1HLD+15 | Β±12HLD+15 | 12HLD+15 | ||
| 544Β±40HLD+15 | ||||||
| G | 590Β±40HLG | 1HLG | Β±12HLG | 12HLG | ||
| 500Β±40HLG | ||||||
| E | 755Β±40HLE | 1HLE | Β±12HLE | 12HLE | ||
| 508Β±40HLE | ||||||
| C | 851Β±40HLC | 1HLC | Β±12HLC | 12HLC | ||
| 590Β±40HLC | ||||||
| Certificates | CE (In processing), UKCA | |||||
| Display screen | 2.8-inch 320*240 graphic dot matrix colour TFT screen. | |||||
| Material selection | Steel and cast steel, alloy tool steel, stainless steel, forged steel, cast aluminium alloy, copper-zinc alloy, copper-tin alloy, gray cast iron, nodular cast iron, pure copper; Select the appropriate material for measurement. | |||||
| Hardness scale | Β HL, HB,Β HRC,Β HRB,Β HV, HS | |||||
| Strength | Οb(tensile strength) | |||||
| Impact direction | 0Β°γ45Β°γ90Β°γ135Β°γ180Β°A total of 5 impact directions | |||||
| Measurement mode | Statistical, multi-unit, line chart, histogram | |||||
| Statistical measure | Max/Min/Avg | |||||
| Thermal printing | 57mm width thermal printing paper | |||||
| Data storage | 900groups | |||||
| Voice prompt | β | |||||
| Bluetooth APP function | β | |||||
| USB Communication | β | |||||
| PC analysis software | β | |||||
| Auto power off | Can be set: 1/ 5 / 10 /30 minutes or cancel | |||||
| Low battery indication | β | |||||
| External power source | Power adapter requirements: DC5V 2A Type-c connector. | |||||
| Charging time | AboutοΌ2ο½4h | |||||
| Battery | 3.7V 2500mAh polymer rechargeable lithium battery. | |||||
| Drop test | 1m | |||||
